B-grade Lapp cable & wire H07Z-K 90°C 1X50 BU 4726029/R50 50m cable bare copper wire

Manufacturer: Lapp Cables & Wires

Designation: H07Z-K 90°C

Conductor material: Copper

Conductor surface: bare

Nominal conductor cross-section: 50 mm²

AWG size: 1

Ladder class: Class 5: finely stranded

Number of wires: 1

Material of the conductor insulation: other

Specification of conductor insulation: other

Wire identification: Color

Vein color: blue

With protective conductor: no

Maximum permissible conductor temperature: 90 °C

Umbrella: no

Side wire: no

Protective case: without

Reinforcement: none

Coat material: none

Halogen-free according to EN 60754-1/2: yes

Flame retardant: according to IEC/EN 60332-1-2

Low smoke according to EN 61034-2: yes

Cold-resistant according to EN 60811-504+505+506: yes

Oil resistant according to EN 60811-404: no

Outer diameter approx.: 14.4 mm

Minimum permissible bending radius, stationary use/permanently installed: 86.4 mm

Permissible cable outer temperature during installation/handling: 5..90 °C

Permissible cable outer temperature after installation without vibration: -40 to 90 °C

Nominal voltage U0: 450 V

Nominal voltage U: 750 V

Length: 350

Width: 350

Height: 120

Product class: Power cable < 1 kV, for fixed installation
