B-grade Lapp 4161104/50 multi-standard wire Sc 2.1 1 x 35 mm² red 50 m cable

Nominal voltage

750V

Cable type

Multi-Standard SC 2.1

Contents

50m

cross-section

1 x 35 mm²

Manufacturer's color

Red

Cross-section (per conductor)

35mm²

Halogen-free

No

insulation

Based on special PVC

Insulation material

PVC

Special features

Flame retardant

Oil resistant

Flexible

type

SC 2.1 1X35 RD

Material (details)

Tinned copper

Outer diameter

11.70mm

Nominal voltage U0

450V

Temperature range, permanently installed (max.)

+105°C

Temperature range, permanently installed (min.)

-40°C

Temperature range, moving (max.)

+105°C

Temperature range, moving (min.)

-40°C

Number of wires

1x

Packaged

Yes

Ladder assembly

Fine-wire

Stranded construction

Fil de cuivre brings fins étamés

test voltage

2500V

Test mark

UL standard 1063 MTW, UL rec. · AWM style 1015 · CSA: TEW · HAR: H07V-K, X07V-K · (VDE 0281/HD 21)

Standards

MULTINORM (MTW) ​​HAR/UL/CSA

fabric by the meter

No

Product type

wire
