B-grade Lapp 0047106 High-temperature wire Ölflex Heat 180 Sif 1 x 0.25 mm² Grey 100 m

Nominal voltage

500V

Cable type

ÖLFLEX HEAT 180 SIF

Contents

100m

cross-section

1 x 0.25 mm²

Manufacturer's color

Gray

Cross-section (per conductor)

0.25mm²

Halogen-free

Yes

Insulation material

silicone

Special features

Heat resistant

Halogen-free

Flame retardant

type

ÖLFLEX HEAT 180 SIF 1X0.25 GY

Outer diameter

1.90mm

Nominal voltage U0

300V

Temperature range, permanently installed (max.)

+180°C

Temperature range, permanently installed (min.)

-50°C

Temperature range, moving (max.)

+90°C

Temperature range, moving (min.)

-35°C

Number of wires

1x

Packaged

Yes

Ladder assembly

Fine-wire

test voltage

2000V

fabric by the meter

No

Product type

High-temperature vein
