B-grade Faber cable 031183 stranded wire SiHF-O 2 x 4 mm² red, sold by the meter, silicone cable, 14 meters

Technical data

Cable type

SiHF-O

Number of wires

2x

Cross-section (per conductor)

4mm²

cross-section

2 x 4 mm²

Special features

Heat resistant

Halogen-free

Oil resistant

UV-resistant

Acid resistant

Manufacturer's color

Red

Outer diameter

11mm

Contents

fabric by the meter

Nominal voltage

500V

Nominal voltage U0

300V

test voltage

2kV

Bending radius (number of outer diameters for fixed installation)

5

Bending radius (number of outer diameters for flexible use)

15

Ladder assembly

Cu, tin-plated, class 5 = fine-wire

Halogen-free

Yes

Shielded

No

Temperature range, permanently installed (min.)

-60°C

Temperature range, permanently installed (max.)

+180°C

type

SiHF-O

Product type

wire
